Sealed Lead Acid Battery 12V 5amp – F1 Terminals
The BT-12V-5AF1 is a 12 volt, 5 amp sealed lead acid, non-spillable, rechargeable battery. This battery is typically used as a replacement battery in security alarm systems, fire alarm panels or security lighting applications.
$16.99
Description
The BT-12V-5AF1 is a 12 volt, 5 amp sealed lead acid, non-spillable, rechargeable battery. This battery is typically used as a replacement battery in security alarm systems, fire alarm panels or security lighting applications.
Specifications
|
Physical Characteristics
|
|
|---|---|
| Type | UPS Replacement |
| Voltage | 12V |
| Amps | 5A |
| Terminal Type | F1 |
| Tab Size | 0.25 inch |
| Container Material | ABS(UL-94HB) |
| Length | 2.8 inches [70mm] |
| Width | 3.5 inches [90mm] |
| Height | 4 inches [102mm] |
| Operating Temperature | 25±3℃ (77±5℉ ) |
|
Performance
|
|
| Internal Resistance | Approx.45mΩ |
| Max. Discharge Current | 75A(5S) |
| Rated Capacity | 5.00AH (20hr, 1.75V/cell,25℃/77℉) 4.82AH (10hr, 1.75V/cell,25℃/77℉) 4.73AH (5hr, 1.75V/cell,25℃/77℉) 4.29AH (3hr, 1.75V/cell,25℃/77℉) 3.23AH (1hr, 1.75V/cell,25℃/77℉) |
| Cycle Use | Charge Current Less Than 0.25CA 14.1V~14.7V@25℃(77℉)Temp. Coefficient -30mV/℃ |
| Floating Use | No limit on Initial Charging Current Voltage 13.5V~13.8V@25℃(77℉)Temp. Coefficient -20mV/℃ |
| Capacity affected by Temperature |
40°C 103% 25°C 100% 0°C 86% -15°C 65% |
| Self-discharge | 3 month Remaining capacity: 91% 6 month Remaining capacity:82% 12 month Remaining capacity:65% |
|
Packaging Information
|
|
| Product Weight | 3.75 lbs [1.7kg] |
|
Warranty Information
|
|
| Warranty | 6 Months |
